Connor-Winfield时钟频率控制元件TCXO编码破解
来源:http://www.yijindz.com 作者:亿金电子 2022年04月26
Connor-Winfield凭借其50多年的丰富历史和丰富经验,继续在频率控制产品设计方面进行创新,以提供一系列高精度、高频和高性能石英振荡器。尽管引入了竞争性谐振器技术,但与目前可用的任何其他频率控制技术相比,基于石英的振荡器在长期和短期稳定性精度以及低抖动和低相位噪声信号生成方面继续提供最高水平的性能.
Connor-Winfield的TCXO晶振提供卓越的性能、出色的一致性和稳定的长期特性,使其成为要求苛刻的通信、数据通信和电信应用的首选。
所有推荐的封装类型都具有削波正弦和/或HCMOS输出以及商业到扩展或工业温度范围。
下面列出了每种推荐封装类型的独特特性。
